| HEAVY DUTY |
| SINGLE NEEDLE |
| DROP FEED, NEEDLE FEED (COMPOUND FEED) |
| ALTERNATING PRESSER FEET |
| LOCKSTITCH MACHINE |
| with CENTRA-LUBEŽ-SEMI-AUTOMATIC LUBRICATION SYSTEM |
| VERTICAL
AXIS ROTARY HOOK |
| REVERSE
FEED |
| SAFETY
CLUTCH |
Specifications
|
|
287R-1 |
| Speed, Max (S.P.M.) |
: |
3000* |
| Clearance Under Foot |
: |
11/32" (8.5mm) |
| Needle Bar Stroke |
: |
1-5/16" (33mm) |
| Needle |
: |
135x17 |
| Stitch Length Max. |
: |
@5 s.p.i. (5mm) |
| Bobbin - Metal |
: |
10656 |
|
- Pre-wound |
: |
G |
| Hook |
: |
13086 |
| Bed Size |
: |
2 9/16" dia. x 10 9/16" (65mm x 268mm) |
| Work Space |
: |
10" (258mm) |
| Stitch Type |
: |
301 |
*Speed depends on thread, material and operation.
Applications
- For sewing light to heavy-weight fabric leather, vinyl, upholstery, synthetics,
canvas and various laminated and coated materials.
- Designed for stitching tubular and curved work.
- Suitable for sewing such products as caps, cushions, boots, shoes, auto, boat and
furniture upholstery, tarpaulins, covers, sails, tents, awnings, umbrellas, tops, bags,
luggage, handbags, travelware, accessories, sports and camping equipment, wearing apparel,
orthopedic appliances, slippers, etc.
- Tape binding, Models 287FS/ 287RFS
Features
- Vertical axis rotary hook.
- Compound feed, walking foot mechanism assures even feeding of several piles or of
slippery materials.
- Stitches per minute - 3000*
- Centra-LubeŽ semi-automatic lubrication system.
- Reverse feed - Model 287R-1/ 287RFS
- Simple wing nut adjustment permits raising and lowering of the center foot to allow
for sewing different thicknesses of material.
- Safety clutch prevents the hook from being damaged.
- Simple adjustment permits the raising and lower of the center foot which allows for
sewing of different thickness of material.
